Radiance Plus

Elegant design with enhanced energy performance and customizable options all for an exceptional value. Manufactured exclusively for ABC Supply Co., Inc.

Features

  • Lifetime warranty includes an accidental glass breakage.

  • Multi-Chambered I-Beam structural mainframe provides superior strength and rigidity while offering the most adaptability for all installation methods.

  • Low-profile tilt latches sit subtly out of view but easily engage when sashes need to be tilted in for cleaning.

  • Dual Function partitioned sloped sill forms a negative pressure pocket that keeps sashes securely in place and water flowing away from your home, even in the most adverse weather conditions.

  • Biomaxx advanced composite locks and keepers are 50% stronger than typical die-cast hardware while remaining lead-free, color-true without fading, warping or chipping.

  • Full balance covers hide internal systems while eliminating unsightly visible sash stops.

  • Solid color-through virgin vinyl maintains a natural appearance and won’t chip, peel, corrode, rot or require painting or scraping.
  • Four-Point fusion welding guarantees the frames and sashes are always strong and square.
  • Integral lift and pull rails are ergonomically engineered for effortless operation while remaining aesthetically appealing.
  • Ashland G3 pivot true balance system utilizes stainless steel coils making sash operation smooth, effortless and whisper-quiet.
  • IdeaSeal™ triple protection weather seal keeps the indoor and outdoor environments separate with an integral interlock, sill compression seal, and multiple rows of weatherstripping.
  • Shadow grooved sash welds replicate the classic look of mitered wood corners.
  • Dual push-button vent latches limit sash movement for your family’s safety and security.
  • Dual and triple pane glass options for maximum efficiency in any climate
  • 13 Decorative Exterior Paint Color Finishes
  • Sentry System integrated tilt-lock streamlines appearance and simplifies operation
  • Tempered, Obscure and STC rated glass options
  • Foam Filled Frame
  • Interior and exterior SDL grid packages
  • 4-9/16″ or 6-9/16″ white prime extension jamb
  • 1-5/8″ wide integral nail fin with 1″ setback for new construction application
  • Foam frame wrap is available for increased insulation
  • WOCD field applied “angel locks”
  • Full line of field applied accessories

Window Styles

Double Hung

Horizontal Slider


Shapes

Vinyl Color

Customize your home by selecting a vinyl color that complements its style and look.

Color Choices

White

Tan

White Interior / Black Laminate Exterior

White Interior / Bronze Laminate Exterior

Laminated Interiors

Colonial Cherry

Cavalier Oak

IntelliGlass Packages

The needs of every home are different and with our specialized glass packages you can find the perfect fit for your home and budget. We offer both dual and triple pane glass options and can meet the EPA’s stringent ENERGY STAR® criteria for any geographic location.

Learn more about IntelliGlass

Hardware

Bio-Maxx locks are color matched to your window unit.

Colors

Hardware is color-matched to the window interior. Bronze hardware is standard on Cavalier Oak and Colonial Cherry.

Modern White

Modern Tan

Modern Bronze

Upgrade Options

Sentry System multi-function locking hardware integrates the lock and tilt functions into the same housing.

Sentry System

Grid Pattern

Available in multiple profile and configurations, grid patterns are designed to further showcase your home’s architectural style. Additional decorative options are available, including simulated divided lites.

Styles

Colonial

Prairie

Perimeter

Double Perimeter

Valance

Grid Profile

Profiles give the stylistic appearance of individual glass panes and are offered in multiple colors and styles.

Styles

Flat (white & tan only) 5/8″

Georgian (color matched, interior/exterior) 3/4″

Pencil Pewter 3/16″

Optional Foam Filled Frame

Foam filled frame insulation that reflects radiant heat, improving strength and insulation efficiency.

Complementary Products

A wide variety of coordinating products are available to complete your home improvement project.
